High-Speed Micro Coaxial Cable Assembly:

Our Micro Coaxial Cable Assembly is a custom-designed high-speed interconnect solution
developed for compact electronic systems requiring excellent signal integrity, low crosstalk,
and high mechanical reliability.

This assembly utilizes ultra-fine micro coaxial wires combined with high-density board-level
connectors and reinforced PCB terminations. It is engineered for applications where
conventional ribbon cables or discrete wires cannot meet performance or space constraints.

Each cable is custom built to customer specifications, supporting proprietary signal definitions,
controlled routing, and mechanical integration requirements.

High-Speed Micro Coaxial Cable Assembly Key Features :

Micro Coaxial Wire Construction
Ultra-fine coaxial conductors provide superior EMI control, reduced signal loss, and stable
high-speed transmission.

High-Density Board Interface
Designed with compact board-mounted connectors and PCB transition for precise signal
breakout and secure mating.

Excellent Signal Integrity
Coaxial geometry minimizes crosstalk and external interference, ideal for high-speed and
sensitive signals.

Mechanical Reinforcement
UV adhesive and tape reinforcement at termination points enhance strain relief and
long-term reliability.

Fully Customizable Design
Cable length, pin mapping, connector type, wire count, and shielding structure can be
tailored to project needs.

High-Speed Micro Coaxial Cable Assembly Technical Specifications :

High-Speed Micro Coaxial Cable Assembly Typical Applications :

High-speed sensor modules

Embedded imaging and vision systems

Compact data transmission modules

Industrial electronics and instrumentation

Custom OEM electronic assemblies

High-Speed Micro Coaxial Cable Assembly Electrical & Mechanical Characteristics :

Wire Type: Micro Coaxial

Signal Type: High-speed, low-noise, proprietary signaling

Assembly Length: Custom

Shielding: Individual coax shielding + bundle protection

Testing: 100% continuity, open/short, insulation resistance

Compliance: RoHS compliant materials and processes

High-Speed Micro Coaxial Cable Assembly Custom Options Available :

We support full OEM and engineering customization, including:

Cable length and routing layout

Pin assignment and signal grouping

Connector series and orientation

PCB shape, mounting holes, and thickness

Shielding level and grounding strategy

Labeling, serialization, and packaging

If your application requires non-standard interfaces or proprietary signaling, our engineering
team can support design validation and sample builds.
